| Thread Diameter Size (TDZ) | 5/8″ | Tool Type | Extension Tap |
| Threads per Inch (TPI) | 11 | Chamfer | Plug |
| Thread Standard | NC | Coating | Uncoated |
| Overall Length (OAL) | 6″ | End Shape | Spiral Point |
| Thread Cutting Part Length (THL) | 1-13/16″ | Style | Plug |
| Connection Diameter Machine Side (DCONMS) | 0.48″ | Cutting Direction (HAND) | Right Hand |
| Flute Count (NOF) | 3 | Measurement Type | Inch |
| Cutting Edge Material | HSS | Series/List # | 113SP |
| Thread Tolerance Class (TCTR) | H3 | Thread Size | 5/8″ - 11 |
| Special Feature | Small Shank |
Product Features
| Remarks | •Small Shank Extension Taps •High Speed Steel Ground Thread | Country of Origin | USA |
Shipping Info
Package Length
6.00000
Package Width
.60000
Package Height
.60000
Package Weight
0.3
